AA3003 Roller Shutter Prepainted Aluminum Coil Roller Shutter Aluminum Coil
Prepainted aluminum roller shutters have become a mainstream choice for commercial
buildings, industrial plants, and garages due to their lightweight, high strength, corrosion
resistance, and aesthetic durability.
Core Advantages of 3003 Prepainted Aluminum Roller Shutters
① Lightweight Yet Durable
3003 aluminum alloy (Al-Mn series) has low density (2.73g/cm³), making it 50% lighter than
steel shutters, reducing load on tracks and motors.
Tensile strength: 110-145MPa, suitable for wind resistance (withstands 6-8 level winds).
② Superior Corrosion Resistance
Manganese content (Mn≈1.2%) enhances corrosion resistance, passing 500-hour salt spray
tests—ideal for coastal or humid areas.
PVDF coating (or PE coating) provides UV and acid rain resistance, with an outdoor lifespan
of 10-15 years.
③ Aesthetic & Customizable
Customizable finishes: wood grain, solid colors (RAL palette), brushed metal, etc.
Optional ventilation designs (round holes/louvered openings) for light and airflow control.
④ Low Maintenance
No rust-proof painting required; easy cleaning with water.
Recommended Applications
Retail Stores:
1.0mm + PVDF coating with louvered vents for security and display.
Underground Garages:
1.2mm + PE coating, cost-effective and moisture-resistant.
Industrial Warehouses:
1.5mm + reinforced frame for high-frequency use.
Comparison with Traditional Shutters
| Feature |
3003 Color-Coated Aluminum |
Steel Roller Shutter |
Stainless Steel Shutter |
| Weight |
Light (≈15kg/m²) |
Heavy (≈25kg/m²) |
Medium (≈20kg/m²) |
| Corrosion Resistance |
Excellent (500h salt spray) |
Requires galvanization (200h) |
Excellent (but costly) |
| Noise Level |
Low (aluminum rails) |
Higher (metal friction) |
Moderate |
Company Advantages
Advanced Equipment
• German SMS Group fully automated coating lines with ±0.01mm thickness precision,
Line Speed: 120m/min (20% faster than industry average data)
• MES system enables real-time production monitoring with ≥99.3% product qualification rate
• Multi-spectral imaging detects micro-defects as small as 0.02mm² with 99.8% recognition accuracy
Technology Patents
♦ Anti-Static Color Aluminum Coil and Continuous Production System
♦ Chromium-Free Passivation Solution for Color-Coated Aluminum Coils and Preparation Method
♦ Production Process for High Solar-Reflectance Color Aluminum Coils
♦ Method for Preparing 3D Wood Grain Aluminum Coil Based on Nanoimprint Technology
♦ Low-Temperature Curing Technology
